2-inch 2 MP Fixed Powered by DarkFighter IR Network Speed Dome
- High quality imaging with 2 MP resolution
- Clear imaging against strong back light due to DWDR technology
- 3D DNR technology delivers clean and sharp images
- HiLookVision cloud service and APP for remote management and views of devices
- Built-in microphone and speakerfor real-time audio security
- Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
- Water and dust resistant IP66
Available models:
Product Data
- Camera
- Image Sensor1/2.7" Progressive Scan CMOS
- Max. Resolution1920 ¡Á 1080
- Min. IlluminationColor: 0.001 Lux @(F1.0, AGC ON), 0 Lux with Light
- Lens
- Focal Length2.8 mm/4 mm
-
FOV
2.8 mm, horizontal FOV 106.1¡ã, vertical FOV 55.8¡ã, diagonal FOV 126.5¡ã
4 mm, horizontal FOV 83.6¡ã, vertical FOV 44.6¡ã, diagonal FOV 99.1¡ã
- ApertureF1.0
- Illuminator
- Supplement Light TypeWhite Light
- Supplement Light RangeWhite Light Distance: up to 30 m
- Smart Supplement LightYes
- PTZ
- Movement Range (Pan)0¡ã to 340¡ã
- Movement Range (Tilt)-5¡ã to 105¡ã
- Pan SpeedPan speed: configurable from 4¡ã to 21¡ã/s
- Tilt SpeedTilt speed: configurable from 4¡ã to 19¡ã/s
- Video
- Video CompressionH.265, H.264, MJPEG
- H.264 TypeBaseline Profile, Main Profile, High Profile
- H.265 TypeMain Profile
-
Main Stream
50 Hz: 25 fps (1920 ¡Á 1080, 1280 ¡Á 720)
60 Hz: 30 fps (1920 ¡Á 1080, 1280 ¡Á 720)
-
Sub-Stream
50 Hz: 25 fps (640 ¡Á 480, 640 ¡Á 360)
60 Hz: 30 fps (640 ¡Á 480, 640 ¡Á 360)
- Video Bit Rate32 Kbps to 8 Mbps
- Audio
- Audio CompressionG.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/AAC-LC/PCM
- Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
- Audio Sampling Rate8 kHz/16 kHz
- Environment Noise FilteringYes
- Network
- ProtocolsIPv4/IPv6, HTTP, HTTPS, Qos, DNS, DDNS, NTP, RTSP, RTP, TCP/IP, UDP, DHCP, Bonjour
- APIOpen Network Video Interface, ISAPI, SDK
- Image
- Image SettingsSaturation, brightness, contrast, sharpness
- Wide Dynamic Range (WDR)Digital WDR
- Image EnhancementBLC, HLC, 3D DNR
- Interface
- Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-board StorageBuilt-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
- Built-in MicrophoneYes
- Built-in SpeakerYes
- ResetYes
- Event
- Basic EventMotion detection, video tampering alarm, exception
- Alarm LinkageUpload to FTP, notify surveillance center, send email, upload to memory card
- General
-
Operating Condition
With supplement light on: -30 ¡æ to 40 ¡æ. Humidity 95% or less (non-condensing)
With supplement light off: -30 ¡æ to 50 ¡æ. Humidity 95% or less (non-condensing)
- General FunctionMirror, password protection, watermark
-
Power
12 VDC ¡À 25%, 0.75 A, max. 9 W, ?5.5 mm coaxial power plug, reverse polarity protection
PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.3 A, max. 10 W
-
Dimensions
Camera dimension: 162 mm ¡Á 120 mm ¡Á 234.2 mm (6.4" ¡Á 4.7\" ¡Á 9.2\")
Package dimension: 205 mm ¡Á 167 mm ¡Á 289 mm (8.1 ¡Á 6.6\" ¡Á 11.4\")"
-
Weight
Camera weight: 780 g (1.7 lb.)
With package weight: 1280 g (2.8 lb.)
- Approval
-
EMC
FCC: 47 CFR Part 15, Subpart B;
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014;
IC: ICES-003: Issue 7
- ProtectionIP66 (IEC 60529-2013)
